3 in stock
Top-tier white wall-mounted unit with A+++ rating for spacious open-plan areas
• 6.9 kW output – ideal for rooms up to 65 m²
• Energy class A+++, SEER 8.5 – exceptional efficiency at high output
• SCOP 4.6 – powerful yet cost-efficient heating for large spaces
• Year-round operation – heating and cooling all year from one unit
• R16 refrigerant – engineered for demanding high-output use
• Classic white finish – neutral and discreet in any interior
• High airflow capacity – rapidly conditions spacious open-plan areas
5-Year Manufacturer’s Warranty Every Rotenso unit comes with a 5-year manufacturer’s warranty for complete peace of mind. Your investment is protected against any manufacturing defects – parts and unit replacement included.
5-year warranty on all Rotenso units
Valid when installed by a qualified F-Gas registered engineer
UK after-sales technical support included
Contact us for warranty claims: info@olsh.co.uk
£1,536.00 inc. VAT
3 in stock
£1,536.00 inc. VAT
3 in stock
Top-tier white wall-mounted unit with A+++ rating for spacious open-plan areas
• 6.9 kW output – ideal for rooms up to 65 m²
• Energy class A+++, SEER 8.5 – exceptional efficiency at high output
• SCOP 4.6 – powerful yet cost-efficient heating for large spaces
• Year-round operation – heating and cooling all year from one unit
• R16 refrigerant – engineered for demanding high-output use
• Classic white finish – neutral and discreet in any interior
• High airflow capacity – rapidly conditions spacious open-plan areas
5-Year Manufacturer’s Warranty Every Rotenso unit comes with a 5-year manufacturer’s warranty for complete peace of mind. Your investment is protected against any manufacturing defects – parts and unit replacement included.
5-year warranty on all Rotenso units
Valid when installed by a qualified F-Gas registered engineer
UK after-sales technical support included
Contact us for warranty claims: info@olsh.co.uk
£1,536.00 inc. VAT
3 in stock
—-
| Model | Teta 6,9 kW | |
|---|---|---|
| Cooling | ||
| Capacity | Nom. (Min. – Max.) | 6910 W (1830–7820) |
| Rated input | Nom. (Min. – Max.) | 1940 W (410–2830) |
| Operating current | Nom. (Min. – Max.) | 8,4 A (1,8–12,3) |
| Heating | ||
| Capacity | Nom. (Min. – Max.) | 7100 W (1850–7960) |
| Rated input | Nom. (Min. – Max.) | 1810 W (420–3010) |
| Operating current | Nom. (Min. – Max.) | 7,9 A (1,8–13,1) |
| Reversible heat pump type | air-to-air | |
| Design load in cooling mode | 6,9 kW | |
| SEER | 8,5 W/W | |
| Energy efficiency class, cooling | A+++ | |
| Annual electric energy consumption, cooling | 285 kWh/a | |
| Design load in heating mode (Tbiv -7°C) | 5,5 kW | |
| SCOP | 4,6 W/W | |
| Energy efficiency class, heating | A++ | |
| Annual electric energy consumption, heating | 1674 kWh/a | |
| Dehumidification | 2,0 l/h | |
| Maximum energy consumption | 3010 W | |
| Maximum operating current | 13,1 A | |
| Indoor unit — TA70Xi R16 | ||
| EAN product code | 5905567606519 | |
| Fan speed | T / H / M / L / ML / S | 1220 / 1130 / 990 / 910 / 850 / 750 rpm |
| Air flow | T / H / M / L / ML / S | 1100 / 1030 / 910 / 780 / 690 / 540 m³/h |
| Sound pressure level | T / H / M / L / ML / S | 48 / 45 / 40 / 34 / 30 / 26 dB(A) |
| Sound power level | 58 dB(A) | |
| Rated input | 45 W | |
| Operating current | 0,2 A | |
| Net dimensions W × D × H | 1100 × 222 × 333 mm | |
| Gross dimensions W × D × H | 1165 × 295 × 405 mm | |
| Net weight / Gross weight | 14 / 17 kg | |
| Condensate drain | 16 mm | |
| Outdoor unit — TO70Xo R16 | ||
| EAN product code | 5905567606533 | |
| Fan speed | T / H / M / L / S | 850 / 850 / 750 / 630 / 510 rpm |
| Maximum air flow | 4000 m³/h | |
| Sound pressure level | 59 dB(A) | |
| Sound power level | 69 dB(A) | |
| Net dimensions W × D × H | 967 × 421 × 803 mm | |
| Gross dimensions W × D × H | 1022 × 835 × 480 mm | |
| Bracket spacing W × D | 607 × 390 mm | |
| Net weight / Gross weight | 47 / 50 kg | |
| Refrigerant | ||
| Type | R32 | |
| GWP | 675 | |
| Charge ≤ 5 m | 1,27 kg / 0,858 TCO₂eq | |
| Charged > 5 m | 25 g/mb | |
| Installation / electrical data | ||
| Pipe connections Liquid / Gas | Φ6,35 / Φ12,7 mm (1/4″ / 1/2″) | |
| Maximum installation length | 25 m | |
| Maximum height difference | 10 m | |
| Compressor type | Rotary DC | |
| Power supply | 220–240~50V, 1f | |
| Electrical protection | B20 A | |
| Power cables: outdoor unit | 3 × 2,5 mm² | |
| Indoor–outdoor cables | 5 × 2,5 mm² | |
| Hiro unit–indoor unit cables | – | |
| Indoor operating range Cooling / Heating | 16~32°C / 0~30°C | |
| Outdoor operating range Cooling / Heating | -15~53°C / -25~30°C | |
—-
| Model | Teta 6,9 kW | |
|---|---|---|
| Cooling | ||
| Capacity | Nom. (Min. – Max.) | 6910 W (1830–7820) |
| Rated input | Nom. (Min. – Max.) | 1940 W (410–2830) |
| Operating current | Nom. (Min. – Max.) | 8,4 A (1,8–12,3) |
| Heating | ||
| Capacity | Nom. (Min. – Max.) | 7100 W (1850–7960) |
| Rated input | Nom. (Min. – Max.) | 1810 W (420–3010) |
| Operating current | Nom. (Min. – Max.) | 7,9 A (1,8–13,1) |
| Reversible heat pump type | air-to-air | |
| Design load in cooling mode | 6,9 kW | |
| SEER | 8,5 W/W | |
| Energy efficiency class, cooling | A+++ | |
| Annual electric energy consumption, cooling | 285 kWh/a | |
| Design load in heating mode (Tbiv -7°C) | 5,5 kW | |
| SCOP | 4,6 W/W | |
| Energy efficiency class, heating | A++ | |
| Annual electric energy consumption, heating | 1674 kWh/a | |
| Dehumidification | 2,0 l/h | |
| Maximum energy consumption | 3010 W | |
| Maximum operating current | 13,1 A | |
| Indoor unit — TA70Xi R16 | ||
| EAN product code | 5905567606519 | |
| Fan speed | T / H / M / L / ML / S | 1220 / 1130 / 990 / 910 / 850 / 750 rpm |
| Air flow | T / H / M / L / ML / S | 1100 / 1030 / 910 / 780 / 690 / 540 m³/h |
| Sound pressure level | T / H / M / L / ML / S | 48 / 45 / 40 / 34 / 30 / 26 dB(A) |
| Sound power level | 58 dB(A) | |
| Rated input | 45 W | |
| Operating current | 0,2 A | |
| Net dimensions W × D × H | 1100 × 222 × 333 mm | |
| Gross dimensions W × D × H | 1165 × 295 × 405 mm | |
| Net weight / Gross weight | 14 / 17 kg | |
| Condensate drain | 16 mm | |
| Outdoor unit — TO70Xo R16 | ||
| EAN product code | 5905567606533 | |
| Fan speed | T / H / M / L / S | 850 / 850 / 750 / 630 / 510 rpm |
| Maximum air flow | 4000 m³/h | |
| Sound pressure level | 59 dB(A) | |
| Sound power level | 69 dB(A) | |
| Net dimensions W × D × H | 967 × 421 × 803 mm | |
| Gross dimensions W × D × H | 1022 × 835 × 480 mm | |
| Bracket spacing W × D | 607 × 390 mm | |
| Net weight / Gross weight | 47 / 50 kg | |
| Refrigerant | ||
| Type | R32 | |
| GWP | 675 | |
| Charge ≤ 5 m | 1,27 kg / 0,858 TCO₂eq | |
| Charged > 5 m | 25 g/mb | |
| Installation / electrical data | ||
| Pipe connections Liquid / Gas | Φ6,35 / Φ12,7 mm (1/4″ / 1/2″) | |
| Maximum installation length | 25 m | |
| Maximum height difference | 10 m | |
| Compressor type | Rotary DC | |
| Power supply | 220–240~50V, 1f | |
| Electrical protection | B20 A | |
| Power cables: outdoor unit | 3 × 2,5 mm² | |
| Indoor–outdoor cables | 5 × 2,5 mm² | |
| Hiro unit–indoor unit cables | – | |
| Indoor operating range Cooling / Heating | 16~32°C / 0~30°C | |
| Outdoor operating range Cooling / Heating | -15~53°C / -25~30°C | |
