3 in stock
Powerful yet quiet wall-mounted unit with Wi-Fi for spacious open-plan living
• 7.0 kW output – ideal for rooms up to 65 m²
• Energy class A++, SEER 6.5 – high efficiency for large spaces
• Year-round operation – powerful heating and cooling all seasons
• Triple iAIR filtration – three-stage purification for cleaner indoor air
• Built-in Wi-Fi – remote control via smartphone from anywhere
• Low-noise operation – quiet performance for open-plan living areas
• 4D airflow – automatic louvres for uniform air distribution across large rooms
5-Year Manufacturer’s Warranty Every Rotenso unit comes with a 5-year manufacturer’s warranty for complete peace of mind. Your investment is protected against any manufacturing defects – parts and unit replacement included.
5-year warranty on all Rotenso units
Valid when installed by a qualified F-Gas registered engineer
UK after-sales technical support included
Contact us for warranty claims: info@olsh.co.uk
£1,526.00 inc. VAT
3 in stock
£1,526.00 inc. VAT
3 in stock
Powerful yet quiet wall-mounted unit with Wi-Fi for spacious open-plan living
• 7.0 kW output – ideal for rooms up to 65 m²
• Energy class A++, SEER 6.5 – high efficiency for large spaces
• Year-round operation – powerful heating and cooling all seasons
• Triple iAIR filtration – three-stage purification for cleaner indoor air
• Built-in Wi-Fi – remote control via smartphone from anywhere
• Low-noise operation – quiet performance for open-plan living areas
• 4D airflow – automatic louvres for uniform air distribution across large rooms
5-Year Manufacturer’s Warranty Every Rotenso unit comes with a 5-year manufacturer’s warranty for complete peace of mind. Your investment is protected against any manufacturing defects – parts and unit replacement included.
5-year warranty on all Rotenso units
Valid when installed by a qualified F-Gas registered engineer
UK after-sales technical support included
Contact us for warranty claims: info@olsh.co.uk
£1,526.00 inc. VAT
3 in stock
| Model | Imoto 7,0 kW | |
|---|---|---|
| Cooling | ||
| Capacity | Nom. (Min. – Max.) | 7034 W (3019–8792) |
| Rated input | Nom. (Min. – Max.) | 2340 W (340–3450) |
| Operating current | Nom. (Min. – Max.) | 10,2 A (1,5–15) |
| Heating | ||
| Capacity | Nom. (Min. – Max.) | 7327 W (1524–9466) |
| Rated input | Nom. (Min. – Max.) | 2130 W (300–3150) |
| Operating current | Nom. (Min. – Max.) | 9,3 A (1,3–13,7) |
| Reversible heat pump type | air-to-air | |
| Design load in cooling mode | 7,0 kW | |
| SEER | 6,5 W/W | |
| Energy efficiency class, cooling | A++ | |
| Annual electric energy consumption, cooling | 377 kWh/a | |
| Design load in heating mode (Tbiv -7°C) | 4,9 kW | |
| SCOP | 4,0 W/W | |
| Energy efficiency class, heating | A+ | |
| Annual electric energy consumption, heating | 1730 kWh/a | |
| Dehumidification | 2,4 l/h | |
| Maximum energy consumption | 3700 W | |
| Maximum operating current | 16,1 A | |
| Indoor unit — I70Xi R14 | ||
| EAN product code | 5905567600838 | |
| Fan speed | H / M / L / S | 1100 / 900 / 800 / 700 rpm |
| Air flow | H / M / L / S | 1020 / 830 / 750 / 560 m³/h |
| Sound pressure level | H / M / L / S | 47 / 41,5 / 30,5 / 25 dB(A) |
| Sound power level | 64 dB(A) | |
| Rated input | 58 W | |
| Operating current | 0,3 A | |
| Net dimensions W × D × H | 1080 × 226 × 335 mm | |
| Gross dimensions W × D × H | 1155 × 315 × 415 mm | |
| Net weight / Gross weight | 13,7 / 17,3 kg | |
| Condensate drain | 16 mm | |
| Outdoor unit — I70Xo R14 | ||
| EAN product code | 5905567600845 | |
| Fan speed | H / M / L | 830 / 700 / 550 rpm |
| Maximum air flow | 3500 m³/h | |
| Sound pressure level | 60 dB(A) | |
| Sound power level | 67 dB(A) | |
| Net dimensions W × D × H | 890 × 342 × 673 mm | |
| Gross dimensions W × D × H | 995 × 398 × 740 mm | |
| Bracket spacing W × D | 663 × 348 mm | |
| Net weight / Gross weight | 43,9 / 46,9 kg | |
| Refrigerant | ||
| Type | R32 | |
| GWP | 675 | |
| Charge ≤ 5 m | 1,45 kg / 0,978 TCO₂eq | |
| Charged > 5 m | 24 g/mb | |
| Installation / electrical data | ||
| Pipe connections Liquid / Gas | Φ9,52 / Φ15,9 mm (3/8″ / 5/8″) | |
| Maximum installation length | 50 m | |
| Maximum height difference | 25 m | |
| Compressor type | Rotary DC | |
| Power supply | 220–240V~50Hz, 1f | |
| Electrical protection | B20 A | |
| Power cables: outdoor unit | 3 × 2,5 mm² | |
| Indoor–outdoor cables | 5 × 2,5 mm² | |
| Hiro unit–indoor unit cables | 4 × 1,5 mm² | |
| Indoor operating range Cooling / Heating | 17~32°C / 0~30°C | |
| Outdoor operating range Cooling / Heating | -15~50°C / -22~30°C | |
| Model | Imoto 7,0 kW | |
|---|---|---|
| Cooling | ||
| Capacity | Nom. (Min. – Max.) | 7034 W (3019–8792) |
| Rated input | Nom. (Min. – Max.) | 2340 W (340–3450) |
| Operating current | Nom. (Min. – Max.) | 10,2 A (1,5–15) |
| Heating | ||
| Capacity | Nom. (Min. – Max.) | 7327 W (1524–9466) |
| Rated input | Nom. (Min. – Max.) | 2130 W (300–3150) |
| Operating current | Nom. (Min. – Max.) | 9,3 A (1,3–13,7) |
| Reversible heat pump type | air-to-air | |
| Design load in cooling mode | 7,0 kW | |
| SEER | 6,5 W/W | |
| Energy efficiency class, cooling | A++ | |
| Annual electric energy consumption, cooling | 377 kWh/a | |
| Design load in heating mode (Tbiv -7°C) | 4,9 kW | |
| SCOP | 4,0 W/W | |
| Energy efficiency class, heating | A+ | |
| Annual electric energy consumption, heating | 1730 kWh/a | |
| Dehumidification | 2,4 l/h | |
| Maximum energy consumption | 3700 W | |
| Maximum operating current | 16,1 A | |
| Indoor unit — I70Xi R14 | ||
| EAN product code | 5905567600838 | |
| Fan speed | H / M / L / S | 1100 / 900 / 800 / 700 rpm |
| Air flow | H / M / L / S | 1020 / 830 / 750 / 560 m³/h |
| Sound pressure level | H / M / L / S | 47 / 41,5 / 30,5 / 25 dB(A) |
| Sound power level | 64 dB(A) | |
| Rated input | 58 W | |
| Operating current | 0,3 A | |
| Net dimensions W × D × H | 1080 × 226 × 335 mm | |
| Gross dimensions W × D × H | 1155 × 315 × 415 mm | |
| Net weight / Gross weight | 13,7 / 17,3 kg | |
| Condensate drain | 16 mm | |
| Outdoor unit — I70Xo R14 | ||
| EAN product code | 5905567600845 | |
| Fan speed | H / M / L | 830 / 700 / 550 rpm |
| Maximum air flow | 3500 m³/h | |
| Sound pressure level | 60 dB(A) | |
| Sound power level | 67 dB(A) | |
| Net dimensions W × D × H | 890 × 342 × 673 mm | |
| Gross dimensions W × D × H | 995 × 398 × 740 mm | |
| Bracket spacing W × D | 663 × 348 mm | |
| Net weight / Gross weight | 43,9 / 46,9 kg | |
| Refrigerant | ||
| Type | R32 | |
| GWP | 675 | |
| Charge ≤ 5 m | 1,45 kg / 0,978 TCO₂eq | |
| Charged > 5 m | 24 g/mb | |
| Installation / electrical data | ||
| Pipe connections Liquid / Gas | Φ9,52 / Φ15,9 mm (3/8″ / 5/8″) | |
| Maximum installation length | 50 m | |
| Maximum height difference | 25 m | |
| Compressor type | Rotary DC | |
| Power supply | 220–240V~50Hz, 1f | |
| Electrical protection | B20 A | |
| Power cables: outdoor unit | 3 × 2,5 mm² | |
| Indoor–outdoor cables | 5 × 2,5 mm² | |
| Hiro unit–indoor unit cables | 4 × 1,5 mm² | |
| Indoor operating range Cooling / Heating | 17~32°C / 0~30°C | |
| Outdoor operating range Cooling / Heating | -15~50°C / -22~30°C | |
